GUIDE BALL
GUIDE CONE BALL (16MnCr5) HARDENED
| CODE | A | B | C | LINCH PIN SIZE |
| CI4422 | 22.1 | 44 | 53.5 | 11 |
| CI5622 | 22.1 | 56 | 66 | 11 |
| CI5628 | 28.4 | 56 | 66 | 11 |
| CI5637 | 37.1 | 56 | 66 | 11 |
| CI6428 | 28.4 | 64 | 66 | 11 |
| CI6437 | 37.1 | 64 | 72 | 15 |
| CI6437-11 | 37.1 | 64 | 72 | 11 |
GUIDE CONE BALL (BLACK LINE)
| CODE | A | B | C | LINCH PIN SIZE |
| CI5628 BL | 28.4 | 56 | 66 | 11 |
| CI6428 BL | 28.4 | 64 | 66 | 11 |
| CI6437 BL | 37.1 | 64 | 72 | 15 |
| CODE | A | B | C |
| CI01 | 28.4 | 45 | 24 |
| CI02 | 37.1 | 45 | 24 |
FORGED LINCH PIN WITH CHAIN & WITHOUT CHAIN (HEAT TREATED 18~22 H.R.C.)
| CODE | CODE | A | B | C | D | E |
| CI CHAIN | WITH CHAIN | |||||
| CI 11 | FLPC11 | 11 | 48 | 52 | 4 | 66 |
| CI 15 | FLPC15 | 26 | 56 | 60 | 4 | 75 |
