Tiller Pin/Lower Pin
LOWER LINK PIN / LIFT ARM PIN
| CODE | A | B | C | D | E | F | G | H | I | J |
| CI22-18M | 22 | 46 | 12 | M18X1.5 | 133 | 18 | 5 | 31 | 37 | 45 |
| CI2218M | 22 | 46 | 12 | M20X1.5 | 130 | 20 | 5 | 30 | 36 | 46 |
| CI2211M | 22 | 51 | 12 | M20X1.5 | 128 | 20 | 10 | 30 | 36 | 38 |
| CI2201M | 22 | 51 | 12 | M20X1.5 | 130 | 20 | 5 | 30 | 36 | 40 |
| CI2202M | 22 | 51 | 12 | M22X1.5 | 140 | 22 | 14 | 30 | 38 | 40 |
| CI2205U | 22 | 51 | 12 | 3/4″UNF | 140 | 19 | 6 | 30 | 36 | 48 |
| CI2206U | 22 | 51 | 12 | 5/8″ UNF | 140 | 22 | 11 | 30 | 36 | 43 |
| CI2210U | 22 | 51 | 12 | 7/8″UNF | 138 | 28.6 | 14 | 30 | 36 | 38 |
| CI2216U | 22 | 51 | 12 | 7/8″UNF | 140 | 22 | 5 | 30 | 36 | 46 |
| CI2207U | 22 | 51 | 12 | 7/8″UNF | 146 | 28.6 | 22 | 30 | 36 | 38 |
| CI2204U | 22 | 51 | 12 | 7/8″UNF | 149 | 22 | 11 | 30 | 36 | 54 |
| CI2209U | 22 | 51 | 12 | 1″UNF | 146 | 24 | 9.5 | 30 | 36 | 51 |
| CI22-22M | 22 | 60 | 12 | M22X1.5 | 146 | 22 | 16 | 31 | 38 | 40 |
| CI22-24M | 22 | 60 | 12 | M22X1.5 | 146 | 24 | 16 | 38 | 44 | 40 |
| CI22-25M | 22 | 60 | 12 | M22X1.5 | 146 | 25 | 16 | 38 | 44 | 40 |
| CI22-28M | 22 | 60 | 12 | M22X1.5 | 146 | 28 | 16 | 38 | 44 | 40 |
| CI25-22M | 25 | 60 | 12 | M22X1.5 | 146 | 22 | 16 | 38 | 44 | 40 |
| CI25-25M | 25 | 60 | 12 | M22X1.5 | 146 | 25 | 16 | 38 | 44 | 40 |
| CI25-28M | 25 | 60 | 12 | M22X1.5 | 146 | 28 | 16 | 38 | 44 | 40 |
| CI28-22M | 28 | 60 | 12 | M22X1.5 | 146 | 22 | 16 | 38 | 44 | 40 |
| CI28-24M | 28 | 60 | 12 | M22X1.5 | 146 | 24 | 16 | 38 | 44 | 40 |
| CI28-25M | 28 | 60 | 12 | M22X1.5 | 146 | 25 | 16 | 38 | 44 | 40 |
| CI28-28M | 28 | 60 | 12 | M22X1.5 | 146 | 28 | 16 | 38 | 44 | 40 |
| CI2822M | 28 | 55 | 12 | M24X1.5 | 150 | 24 | 15 | 38 | 44 | 45 |
| CI2823M | 28 | 55 | 12 | M27X1.5 | 150 | 28 | 14 | 38 | 44 | 45 |
| CI2824M | 28 | 58 | 12 | M27X1.5 | 147 | 27 | 10 | 38 | 44 | 48 |
| CI2845M | 28 | 60 | 12 | M27X1.5 | 140 | 28 | 15 | 38 | 44 | 35 |
| CI2836U | 28.6 | 51 | 12 | 3/4″UNF | 141 | 25.4 | 24 | 38 | 44 | 36.5 |
| CI2840U | 28.6 | 60 | 12 | 3/4″UNF | 149 | 19 | 6 | 38 | 44 | 54 |
| CI2842U | 28.6 | 60 | 12 | 7/8″UNF | 136.5 | 22 | 12.7 | 38 | 44 | 35 |
| CI2843U | 28.6 | 60 | 12 | 7/8″UNF | 146 | 22 | 12.7 | 38 | 44 | 44 |
| CI2841U | 28.6 | 60 | 12 | 7/8″UNF | 149 | 28.6 | 22 | 38 | 44 | 38 |
| CI2839U | 28.6 | 60 | 12 | 1″UNF | 149 | 25.4 | 9.5 | 38 | 44 | 51 |
| CI2837U | 28.6 | 57 | 12 | 9/8″UNF | 159 | 28.6 | 16 | 38 | 44 | 60 |
| CI2838U | 28.6 | 60 | 12 | 9/8″UNF | 149 | 28.6 | 9.5 | 38 | 44 | 51 |
| CI3845U | 36 | 54 | 12 | 9/8″UNF | 149 | 28.6 | 16 | 46 | 52 | 48 |
| CI3642M | 36.5 | 61 | 12 | M27X1.5 | 165 | 27 | 11 | 46 | 52 | 60 |
