CODE | CAT d1-d2 | PIPE L1 (INCH) | THREAD D |
THREAD 3/4” UNC | |||
| CI001 | 0-0 | 7.1/2″ | 3/4 UNC |
| CI002 | 0-0 | 9.3/4” | 3/4 UNC |
| CI003 | 0-0 | 190.0mm | 3/4 UNC |
| CI004 | 0-0 | 250.0mm | 3/4 UNC |
| CI005 | 0-0 | 400.0mm | 3/4 UNC |
THREAD 1.1/8” UNC | |||
| CI006 | 1-1 | 7″ | 1.1/8 UNC |
| CI007 | 1-2 | 7″ | 1.1/8 UNC |
| CI008 | 2-2 | 7″ | 1.1/8 UNC |
| CI009 | 1-1 | 9″ | 1.1/8 UNC |
| CI0010 | 1-2 | 9″ | 1.1/8 UNC |
| CI0011 | 2-2 | 9″ | 1.1/8 UNC |
| CI0012 | 1-1 | 11.1/4″ | 1.1/8 UNC |
| CI0013 | 1-2 | 11.1/4″ | 1.1/8 UNC |
| CI0014 | 2-2 | 11.1/4″ | 1.1/8 UNC |
| CI0015 | 1-1 | 13” | 1.1/8 UNC |
| CI0016 | 1-2 | 13” | 1.1/8 UNC |
| CI0017 | 2-2 | 13” | 1.1/8 UNC |
| CI0018 | 1-1 | 14.1/2″ | 1.1/8 UNC |
| CI0019 | 1-2 | 14.1/2″ | 1.1/8 UNC |
| CI0020 | 2-2 | 14.1/2″ | 1.1/8 UNC |
| CI0021 | 1-1 | 16” | 1.1/8 UNC |
| CI0022 | 1-2 | 16” | 1.1/8 UNC |
| CI0023 | 2-2 | 16” | 1.1/8 UNC |
| CI0024 | 1-1 | 17.1/4” | 1.1/8 UNC |
| CI0025 | 1-2 | 17.1/4” | 1.1/8 UNC |
| CI0026 | 2-2 | 17.1/4” | 1.1/8 UNC |
| CI0027 | 1-1 | 20” | 1.1/8 UNC |
| CI0028 | 1-2 | 20” | 1.1/8 UNC |
| CI0029 | 2-2 | 20” | 1.1/8 UNC |
| CI0030 | 1-1 | 24” | 1.1/8 UNC |
| CI0031 | 1-2 | 24” | 1.1/8 UNC |
| CI0032 | 2-2 | 24” | 1.1/8 UNC |
THREAD 1.1/4″ UNC | |||
| CI0033 | 2-2 | 15″ | 1.1/4 UNC |
| CI0034 | 2-2 | 19″ | 1.1/4 UNC |
THREAD 1.3/8” UNC | |||
| CI0035 | 3-3 | 19.1/2” | 1.3/8” UNC |
