WELD ON END WITH SLOT

WELD ON END WITH SLOT

CODE	d	D	A	B	C	E-SLOT	SIDE
CI001	28.4	45	76	85	95	28X45X95	R
CI002	284	45	76	85	95	28X45X95	L
CI003	37	445	94	90	95	28X45X95	R
CI004	37	45	94	90	95	28X45X95	L

TOP LINK LOCKING COLLAR (PWELD ON END WITH BASELATE)

CODE	D	E	A	B	C
CI001	28.4	45	100	130	100
CI002	37	45	100	130	100
CI003	38	45	100	130	100

WELD ON END

CODE	D	A	B	E	C
CI001	45.2	128	85	63	65

WELD ON END WITH CENTERING PIN

CODE	d	D	A	B	C	E	F	G	H
CI001	19	51	75	55	35	12	6	4	4
CI002	22.1	51	75	55	35	12	6	4	4
CI003	25.4	51	75	55	35	12	6	4	4
CI004	30	51	75	55	35	12	6	4	4

WELD ON ENDWELD ON END WITH CENTERING PIN

CODE	D	E	A	B	C
CI001	25.4	44	80	72	75
CI002	28.4	44	80	72	75
